Specifications:

• Brand Name: NEUTRIK
• Item Type: XLR
• Insertion force #2: ≤ 20 N
• Rated current per contact #2: 3 A (XLR),3 A (Jack)
• Gender: Female
• Contacts: Bronze (CuSn6)
• Locking element: Steel Ck67
• Panel thickness #2: max. 3 mm (0.12'')
• Contact resistance #1: < 20 mΩ (jack)
• Withdrawal force #2: ≤ 20 N
• Insulation resistance: > 10 GΩ (initial)
• Withdrawal force #1 #3: ≤ 25 N
• Panel thickness #1 #3: max. 7 mm 0.27"
• Origin: CH(Origin)
• Mounting direction: Rear mounting
• Manufacture: NEUTRIK AG
• Insertion force #1 #3: ≤ 25 N
• Packing: 1 pcs
• Contact resistance #3: < 20 mΩ (jack)
• Contact resistance: < 10 mΩ (XLR)
• Certification: RoHS
• Mounting screw #2: A-screw
• Rated voltage: < 50 V
• Connection Type: Combo
• Dielectric strength: 1.5 kVdc
• Rated current per contact #1: 7.5 A (XLR),7.5 A (Jack)
• Locking device #2: Latch lock
• Insert: PA66
• Contact resistance #2: < 10 mΩ (jack)
• Model Number: NCJ6FI-S,NCJ6FA-H,NCJ6FI-H
• Wiring #2: Horizontal PCB mount
• Flammability: UL 94 V-0
• Temperature range: -30 °C to +80 °C
• Rated current per contact #3: 7.5 A (XLR),7.5 A (Jack)
